REMARKS

New Model: 15-08-25
'**MS Office Home 2024 Malaysia + 1yr M365 Basic &
 MISC PC Game Pass DA 3M
400 W 80 Plus Platinum certified power supply

PROCESSOR

Intel® Core™ Ultra 5 225 (up to 4.9 GHz with Intel® Turbo Boost Technology, 20 MB L3 cache, 10 cores, 10 threads)
Intel® AI Boost (13 NPU TOPS)

MEMORY (STD/MAX)

RAM 16GB (1x16GB) DDR5 5600

EXTRA RAM SLOT

1

PCI EXPRESS SLOT

2 (1 x PCIe x16 Gen4,1 x PCIe x1 Gen3)

M.2 Expansion Slots

2
Socket 1 2230 type for WLAN
Socket 3 Key M type 2280/2230 for SSD (PCIe x4) (CPU) Gen4

Extra Hard Disk SLOT

NA

HARD DISK DRIVE

SSD 512GB 2280 PCIe NVMe Value

OPTICAL DRIVE

NA

WIRELESS

Intel® Wi-Fi 6E AX211 (2x2) and Bluetooth® 5.3 wireless card

OPERATING SYSTEM

Windows 11 (64-bit) Plus

CHIPSET

Intel® B860

GRAPHIC CRAD

Down Integrated In Chipset

AUDIO

ALC3602-CG

NETWORKING

Integrated 10/100/1000 GbE LAN

CARD READER

NA

FRONT ACCESS

2  USB Type-A 5Gbps signaling rate;
1 USB Type-C® 5Gbps signaling rate;
2  USB Type-A 10Gbps signaling rate;
1 USB Type-C® 10Gbps signaling rate;
Headphone/MIC Combo Jack

REAR ACCESS

4 USB 2.0 Type-A; 1 RJ-45
5.1 ch support; x1 (HDMI v2.1, HDCP 2.3); x1 (DP v1.4a, HDCP 2.3);
3# of Rear I/O Panel 3.5mm Audio Jacks (Line-in/Line-out/Mic)

KEYBOARD & MOUSE

Black wired non-plastic Copilot KBD 125 & BLK WD NP MSE 125 (C/C)

MEDIA DRIVE BAY

None

TV TUNER

None

REMOTE CONTROL MODULE

None

WEBCOM/MIC

None

SOFTWARE

-

DISPLAY

None

WARRANTY

3 years Parts & Labour (onsite) limited warranty with up-and-running phone support for first 30 days
